Technical featurese
Conductor
Red copper wire, annealed, not tinned
Insulation
Rubber compound EM5
Separator
Kraft paper
Rated voltage Uo/U
100/100V
Working temperature
-20°C / +85°C maximum on conductor
Max. Temperature in case of short circuit
250°C on the conductor (maximum duration 5 seconds)
Minimum bending radius
Mobile installation: 4 times the outer diameter
Maximum laying stress
15N for mm² of copper total section
Standard sheath colour
Black
Standard marking
Eproflex iemmequ <HAR> H01N2-D + mm² + CE + year + Lot.
Identification thread
< HAR > (black-red-yellow)
Distance between markings
Every20/25cm. about
Means of marking
Inkjet
Nominal cross sectional area of conductor
Maximum diameter of wire of conductor
Thickness of covering
Mean overall diameter
Maximum conductor resistance at 20°C
Capacity of conductor at 60% duty cycle
Capacity of conductor at 35% duty cycle
mmq
mm
mm
mm
Ohm/Km
Ampère
Ampère
10
0,21
2
8,2
1,91
108
122
16
0,21
2
9,2
1,21
175
230
25
0,21
2
10,7
0,78
230
300
35
0,21
2
12,4
0,554
290
375
50
0,21
2,2
14,2
0,386
365
480
70
0,21
2,4
16,4
0,272
460
600
95
0,21
2,6
19
0,206
560
730
120
0,21
2,8
21
0,161
650
850
